FOG technology

Explore the working principles, military/civilian applications, and market prospects of tactical-grade fiber optic gyroscopes (FOGs). Learn about top products like GF-3G70 and GF-3G90, and discover their role in aerospace, UAVs, and more. 1. Introduction In the field of modern inertial navigation, Fiber Optic Gyroscopes (FOGs) have become one of the mainstream devices due to their unique advantages. Today, we will delve into the working principles, current market status, and typical product applications of this technology, with a special focus on the performance characteristics of tactical-grade fiber optic gyroscopes. 2. Working Principles of Fiber Optic Gyroscopes A fiber optic gyroscope is an all-solid-state fiber optic sensor based on the Sagnac effect. Its core component is a fiber optic coil, where light emitted by a laser diode propagates in two directions along the coil. When the system rotates, the propagation paths of the two light beams produce a difference. By measuring this optical path difference, the angular displacement of the sensitive component can be precisely determined. Simply put, imagine emitting two beams of light in opposite directions on a circular track. When the track is stationary, the two beams will return to the starting point simultaneously. However, if the track rotates, the light moving against the rotation direction will "travel a longer distance" than the other beam. The fiber optic gyroscope calculates the rotation angle by measuring this minute difference. 3. Technical Classification and Market Status Based on their working methods, fiber optic gyroscopes can be divided into: Interferometric Fiber Optic Gyroscope (I-FOG) Resonant Fiber Optic Gyroscope (R-FOG) Brillouin Scattering Fiber Optic Gyroscope (B-FOG) In terms of accuracy levels, they include: Low-end tactical gradeHigh-end tactical gradeNavigation gradePrecision grade Currently, the fiber optic gyroscope market exhibits dual-use characteristics for military and civilian applications: Military applications: Attitude control for fighter jets/missiles, tank navigation, submarine heading measurement, etc. Civilian applications: Car/aircraft navigation, bridge measurement, oil drilling, etc. It is worth noting that medium-to-high precision fiber optic gyroscopes are primarily used in high-end military equipment such as aerospace, while low-cost, low-precision products are widely applied in civilian fields like oil exploration, agricultural aircraft attitude control, and robotics. 4. Technical Challenges and Development Trends The key to achieving high-precision fiber optic gyroscopes lies in: 1. Studying the impact of optical devices and physical environments on performance. 2. Suppressing relative intensity noise. With the advancement of optoelectronic integration technology and specialty optical fibers, fiber optic gyroscopes are rapidly developing toward miniaturization and cost reduction. Integrated, high-precision, and miniaturized fiber optic gyroscopes will become the mainstream in the future. 5. Recommended Tactical-Grade Fiber Optic Gyroscope Products Taking Micro-Magic Company's products as an example, their tactical-grade fiber optic gyroscopes are characterized by medium precision, low cost, and long lifespan, offering significant price advantages in the market. Below are two popular products: GF-3G70 Performance Characteristics:Bias stability: 0.02~0.05°/h Typical Applications:Electro-optical pods/flight control platformsInertial Navigation Systems (INS)/Inertial Measurement Units (IMU)Platform stabilization devicesPositioning systemsNorth seekers GF-3G90 Performance Characteristics:Higher bias stability: 0.006~0.015°/hLong lifespan, high reliability Typical Applications:UAV flight controlMapping and orbital inertial measurementElectro-optical podsPlatform stabilizers 6. Conclusion Fiber optic gyroscope technology holds significant strategic importance for a country's industrial, defense, and technological development. With technological advancements and the expansion of application scenarios, fiber optic gyroscopes will play a critical role in more fields. Tactical-grade products, with their excellent cost-performance ratio, are gaining widespread application in both military and civilian markets. G-F3G70 Tri-Axis Fiber Optic Gyroscope G-F70ZK Medium and High Precision  Fiber Optic Gyroscope G-F3G90 Tri-Axis Fiber Optic Gyroscope --
