As a new type of all-solid state gyro, fiber optic gyroscope has the advantages of fast start, wide measurement range and high reliability. G-F60 uniaxial medium and low precision fiber optic gyroscope can be applied to the application requirements of high precision inertial navigation system, such as land positioning orientation, vehicle north finding instrument, airborne navigation posture and Marine gyro. The specification is only applicable to G-F60 type products, including performance indicators, technical conditions, external dimensions and installation and use. Among them, the technical conditions include the environmental range, electrical performance and physical characteristics of the product.
Part No, :
G-F60Order(MOQ) :
1Protection Level :
IP67Connector :
RS422Product Series and Parameters
| G-F60-A | G-F60-B | G-F60-C | Unit | |
| Zero bias stability | ≤0.20 | ≤0.10 | ≤0.05 | °/hr (1σ,10s) |
| Stabilization time | ＜5 | ＜5 | ＜5 | s |
| Zero bias repeatability | ≤0.20 | ≤0.10 | ≤0.05 | °/hr (1σ) |
| Full-temperature zero-bias repeatability | ≤1 | ≤0.5 | ≤0.3 | °/hr |
| Random walk coefficient | ≤0.02 | ≤0.01 | ≤0.005 | °/ |
| The Scale factor of Nonlinearity | ≤100 | ≤50 | ≤50 | ppm (1σ) |
| The Scale factor of Repeatability | ≤100 | ≤50 | ≤50 | ppm (1σ) |
| Dynamic range | ±500 | °/s | ||
| Magnetic field sensitivity | ≤0.10 | °/hr/Gs | ||
| Working temperature | -40～+70 | ℃ | ||
| Storage temperature | -50～+70 | ℃ | ||
| Vibration conditions | 4.2g, 20～2000 | Hz | ||
Production process
Product dimension
Graph 2 Outline dimensions of G-F60
